| Seri |
Hino 300 Dutro |
| Category |
Truck |
| Karoseri |
Arm Roll, Bak Terbuka, Dump, Fire Fighting, Mesin Derek, Molen, Tangki, Truk Logging |
| Kecepatan Maksimum (km/jam) |
83 |
| Daya Tanjak (tan Ø) |
56 |
| Model Mesin |
W04D-TR |
| Tipe Mesin |
Mesin Diesel 4 Langkah Segaris; Direct Injection; Turbo Charge Intercooler |
| Tenaga Maksimum (PS/rpm) |
130 / 2700 |
| Torsi Maksimum (Kgm/rpm) |
38 / 1800 |
| Jumlah Silinder |
4 |
| Diameter x Langkah Piston (mm) |
104 x 118 |
| Isi Silinder (cc) |
4009 |
| Tipe Kopling |
Pelat Kering Tunggal; Hydraulic Operation |
| Diameter Cakram Kopling |
300 |
| Tipe Transmisi |
M550 |
| ke-1 |
4,981 |
| ke-2 |
2,911 |
| ke-3 |
1,556 |
| ke-4 |
1,000 |
| ke-5 |
0,738 |
| Mundur |
4,625 |
| Tipe-Kemudi |
Recirculating Ball Screw |
| Minimal Radius Putar (m) |
6,7 |
| Sumbu Depan |
Reverse Elliot, I-Section Beam |
| Sumbu Belakang |
Full Floating Type, Single Reduction, Single Speed by Hypoid Gear |
| Perbandingan Gigi Akhir |
6,833 |
| Sistem Penggerak |
Rear 4×4 |
| Rem Utama |
Vacuum Servo dengan Sirkuit Ganda; Dilengkapi Booster |
| Rem Pelambat |
Dengan Pipa Gas Buang |
| Rem Parkir |
Internal Expanding; Out Shaft Transmisi |
| Ukuran Rim |
16 x 6,00GS-127 |
| Ukuran Ban |
7,50-16-14PR |
| Jumlah Ban |
6+1 |
| Suspensi Depan & Belakang |
Rigid Axle with Semi Elliptic with Shock Absorber |
| Accu |
12V-60Ah x2 |
| Kapasitas Tangki Solar (L) |
100 |
| Dimensi (mm) |
Ukuran Dimensi Unit |
| Jarak Sumbu Roda |
3380 |
| Cabin to Axis |
2900 |
| Total Panjang |
6026 |
| Total Lebar |
1945 |
| Lebar Jejak Depan |
1527 |
| Lebar Jejak Belakang |
1480 |
| Julur Depan |
1066 |
| Julur Belakang |
1580 |
| Berat Chassis Depan (kg) |
1651 |
| Berat Chassis Belakang (kg) |
1022 |
| Berat Kosong |
2673 |
| GVWR / GCWR |
8300 |
